SAB GOBLIN 570 KYLE STACY EDITION (With Main and Tail Blades)

SAB Heli Division
SABSG577
Bestel
  • Beschrijving

 SAB GOBLIN 570 KYLE STACY EDITION (With Main and Tail Blades)

  • The Goblin 570 Kyle Stacy Edition is the Goblin 570 with the yellow Carbon canopy /boom and with 3 blades Head.
  • In the Kit also the new Main gear CNC H0423-S
  • The Goblin 570 Kyle Stacy Edition is the Goblin 570 with the yellow Carbon canopy /boom and with 3 blades Head (H0490-K)
  • In the Kit also the new Main gear CNC H0423-S

Kyle Stacy flying the Goblin 570 KSE: https://www.youtube.com/watch?v=jsTe9-Q0p_I

Kyle Stacy flying the Goblin 570 KSE (in red color)  at the beach: https://www.youtube.com/watch?v=r8EuUkXjaWk

Kyle Stacy said about Goblin 570 KSE:
The Goblin 570 Kyle Stacy Edition is the perfect helicopter for either learning to fly or perfecting your 3D maneuvers. Being able to run on 6 cell battery or a 12 cell setup makes it one of the most versatile machines available.
The HPS 3 rotor head makes it an incridibly smooth, stable and agile machine, all while maintaining it's strong presence in the air. This is my absolute favourite helicopter to fly and i hope you love it as much as i do.

General Specifications:
Main rotor diameter: 1218 mm (with 540 mm tri-blades)
Main blade length support: 540 to 575mm
Tail rotor diameter: 278 mm
Tail blade length: 104 mm
Main shaft diameter: 10 mm
Spindle shaft diameter: 8 mm
Weight including electronics: about 2450 g (excluding batteries)

Special Features:
Full carbon boom & Canopy
Battery tray for 6S and 12S packs
Inside carbon rod
Dampened tail system

Electronics:
Cyclic Servos: Standards size 40mm
Tail Servo: Standard size (40mm)
Typical Speed Controller: 6S 100A / 12S 80A
Maximum motor size: 4025 size (52 mm diameter, 56 mm height)
6S 1000-1400 Kv / 12S 500-700 Kv / 12S 500-700 Kv
Battery compartment: 6S 5000/5500 mAh, Max dimension 50x60x200mm / 12S 2600/3300 mAh Max dimension 50x45x280mm

Kit Includes:
21T motor pulley (other pulley sizes available)
1 battery tray with straps
540 mm  tri-blades main rotor set
104 mm tail blades

Key Features:
HPS3 main rotor head
10mm high strength steel main shaft
8mm high strength steel spindle shaft
2mm carbon frames
Stronger CNC main gear, Gates GT3 motor belts, 10 mm one-way bearing
Strong landing gear. Landing gear mounting brackets do not require bolts to be installed. The brackets are a break point during a crash preserving frames and other important parts
Aluminum tail case for increased stiffness
Dampened tail system for increased vibration tolerance
6S and 12S battery
Battery tray with lock system
Nylon bolt break-away system to preserve the boom during a crash
Aluminium ESC Support
Standard size cycling & Tail servos
Canopy saver, protects the canopy edges from scuffing.

The following motor pulleys are available:
H0215-16-S-16T Pinion = ratio 12.9:1
H0215-17-S-17T Pinion = ratio 12.2:1
H0215-18-S-18T Pinion = ratio 11.5:1
H0215-19-S-19T Pinion = ratio 10.9:1
H0215-20-S-20T Pinion = ratio 10.3:1
H0215-21-S-21T Pinion = ratio 9.8:1
H0215-22-S-22T Pinion = ratio 9.4:1
H0215-23-S-23T Pinion = ratio 9:1
H0215-24-S-24T Pinion = ratio 8.5:1
All these motor pulleys are for a 6 mm motor shaft. Each pulley includes an adapter for 5 mm motor shafts.
